Wet mix plant with CTABS (Cement treated aggregate base system)

Wet Mix Macadam Plant
Wet Mix Macadam Plant

Our Wet mix plant with CTABS (Cement treated aggregate base system) is a specialized road construction solution designed to produce high-strength, durable base layers by blending aggregates with controlled quantities of cement and water. This advanced system enhances the load-bearing capacity and longevity of pavements, making it ideal for highways, airports, industrial roads, and other heavy-duty infrastructure projects.

With the addition of the Cement Treated Aggregate Base System, this plant provides a cost-effective and time-saving solution for constructing rigid pavement sub-bases. The integration of cement into the mix not only improves structural integrity but also minimizes deformation and cracking under heavy loads. Its modular design enables quick setup and easy transportation between job sites, making it a reliable choice for both small-scale and large-scale infrastructure projects. Backed by Himalaya Engineering Company’s commitment to quality and performance, this plant ensures consistent output, reduced material wastage, and enhanced pavement lifespan.

Features Of Wet mix plant with CTABS

Applications Of Wet mix plant with CTABS

specification Of Wet mix plant with CTABS

MODELWMM-100 TPHWMM-120 TPHWMM-160 TPHWMM-200 TPHWMM-250 TPH
FEEDER (COLD FEEDER)
Gathering Conveyor Belt Side600 mm x 25.5 Mtr.600 mm x 25.5 Mtr.600 mm x 25.5 Mtr.600 mm x 25.5 Mtr.600 mm x 25.5 Mtr.
Belt Feeder500 mm x 2.9 Mtr.500 mm x 2.9 Mtr.500 mm x 2.9 Mtr.500 mm x 2.9 Mtr.500 mm x 2.9 Mtr.
No. of Bins4 Nos4 Nos4 Nos4 Nos4 Nos
Bin Cap40 Tons40 Tons40 Tons40 Tons40 Tons
Plate5 mm5 mm5 mm5 mm5 mm
S. M. S. R. GearJigar Stander CompanyJigar Stander CompanyJigar Stander CompanyJigar Stander CompanyJigar Stander Company
Rubber BeltDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./Jhonson
PUG MILL UNIT
Pugmil Unit8 mm8 mm8 mm8 mm8 mm
Pugmil Unit Liner Plant8 mm8 mm8 mm8 mm8 mm
Reduction GearElecon / GreavesElecon / GreavesElecon / GreavesElecon / GreavesElecon / Greaves
LOAD OUT CONVEYOY & SLINGER CONVEYOR
Electric Motor [A.C]Kirlosker / Crompton /
Siemens/ Hindustan Motors
Kirlosker / Crompton /
Siemens/ Hindustan Motors
Kirlosker / Crompton /
Siemens/ Hindustan Motors
Kirlosker / Crompton /
Siemens/ Hindustan Motors
Kirlosker / Crompton /
Siemens/ Hindustan Motors
S. M. S. R. GearJigar Stander CompanyJigar Stander CompanyJigar Stander CompanyJigar Stander CompanyJigar Stander Company
Rubber BeltDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./JhonsonDunlop / M.R.F./Jhonson
POWER REQUIREMENTS
Pug mill unit20 HP30 HP40 HP40 HP40 HP
Feeders (4 Bin)04 x 2 HP04 x 2 HP04 x 2 HP04 x 2 HP04 x 3 HP
Feeder Gathering Conveyor05 HP05 HP05 HP05 HP7.5 HP
Bin Vibrator01 HP01 HP01 HP01 HP01 HP
Slinger Conveyor03 HP05 HP7.5 HP7.5 HP7.5 HP
Vibrating Screen01 HP01 HP01 HP01 HP01 HP
Load out Conveyor03 HP05 HP7.5 HP7.5 HP10 HP
Hydraulic Power Pack03 HP03 HP03 HP03 HP03 HP
Water Pump02 HP02 HP02 HP02 HP02 HP
STORAGE SILONANANA1 Ton - 1 unit
Screw ConveyorNANANA05HP05HP
Rotary ValveNANANA02HP02HP
MATERIALMS PLATE /TATA /
ESSAR / JSW
MS PLATE /TATA /
ESSAR / JSW
MS PLATE /TATA /
ESSAR / JSW
MS PLATE /TATA /
ESSAR / JSW
MS PLATE /TATA /
ESSAR / JSW
"CTABS (Cement treated aggregate base system"
Cement filler system 40 bag capacity with Screw conveyor Cement filler system 40 bag capacity with Screw conveyor Cement filler system 40 bag capacity with Screw conveyor Cement filler system 40 bag capacity with Screw conveyor "Cement filler system 40 bag capacity with Screw conveyor "
EMOLSON Bitumen TankEMOLSON Bitumen Tank With accessories -20 capacityEMOLSON Bitumen Tank With accessories -20 capacityEMOLSON Bitumen Tank With accessories -20 capacityEMOLSON Bitumen Tank With accessories -20 capacityEMOLSON Bitumen Tank With accessories -20 capacity
